craft show
| layers | 6l |
| board thickness | 1.6±0.16mm |
| material | sl s1000h |
| line width / space | 0.152/0.15mm |
| minimum aperture | 0.25mm |
| resistance welding | 10-50um |
| thermal grease | 120 /20um |
| surface treatment | immersiontin |
founded in 2017, zhuhai suntak circuit technology co., ltd. (zhuhai plant) is a wholly-owned subsidiary of suntak technology co., ltd. it is a high-tech enterprise engaged in producing electronic circuits. zhuhai plant covers an area of 260,000㎡, and the master construction plan was completed in three phases, including zhuhai no. 1 plant, zhuhai hdi plant, and zhuhai high-layer board plant, of which the overall construction area and floor area of zhuhai no. 1 plant are about 100,000㎡ and 30,000㎡ respectively, and the products mainly include multi-layer boards, which have been applied in automotive, computers, optoelectronics, etc.
267k㎡
500
automotives, computer, optoelectronics , mobile phone
180,000㎡
craft show
| layers | 6l |
| board thickness | 1.6±0.16mm |
| material | sl s1000h |
| line width / space | 0.152/0.15mm |
| minimum aperture | 0.25mm |
| resistance welding | 10-50um |
| thermal grease | 120 /20um |
| surface treatment | immersiontin |
craft show
| layers | 8l |
| board thickness | 1±0.1mm |
| material | s100h |
| line width / space | 0.091/0.05mm |
| minimum laser drilling aperture | 0.2mm |
| surface treatment | sink gold |
craft show
| layer | 6l |
| board thickness | 2mm |
| material | it180a |
| width/ line spacing | 0.142/0.06mm |
| minimum aperture | 0.2mm |
| surface treatment | osp |
craft show
| layers | 6l |
| board thickness | 1.0mm |
| size | 588*78mm |
| minimum aperture | 0.2mm |
| surface treatment | sink gold |
zhejiang dahua strategic supplier award
preh joyson outstanding contribution award
hikvision best quality award
best quality award
bosch outstanding supplier
become a world-leading manufacturer of circuit board
